MG-G350BSW
350W 3in1 Shaking Head Light
(pattern/dye/beam Without CMY)


Voltage: 100V-240V/50-60Hz,
Ballast: original OSRAM electronic ballast
Light source: OSRAM SIRIUS HRI350 or PHILIPS
Color temperature: 7500K
Average life: 1500H
Number of channels: 2 DMX Modes 16/24 Channels DMX
Control mode: 16 international standard DMX512 control, master-slave mode, self-propelled mode, voice control mode.
LCD liquid crystal display, DMX 3-core signal input
Lens: anti-reflective coated glass lens
Color: with 14 colors+blank with full-color or half-color function, with UV heat shield, optional CMY color mixing system
Fixed pattern: with 14 fixed pattern pieces+blank
Rotating pattern: with 8 rotating patterns and blank, the pattern chip can be freely inserted and replaced
Strobe: 0-13 times/second. With random strobe
Prism and prism rotation: rotate 3 prisms, which can rotate in both directions and prism rotation, with a 16-prism macro function effect.
Soft light effect: the flare angle of soft light can be adjusted
Aperture: 5% to 100% with aperture effect
Focusing: linear electronic focusing
Dimming: 0-100% linear adjustment
Horizontal 540 °, 8Bit/16Bit fine adjustment
The system is equipped with lamp use duration function, RDM remote address code function, automatic feedback signal, automatic error correction function, overheat protection function
Horizontal 540 °, 16Bit vertical 270 °, 16Bit
Beam angle: 5 ° to 27 °
Stroboscopic: double-chip stroboscopic (0.5-9 times/second)
Number of motors: 16 ultra-silent motors, two three-phase motors, 16Bit drive
Other functions: remote control bulb switch function, display lamp and bulb service time,
Appearance: high-temperature resistant plastic+molded alloy material
Protection grade: Ip20
Power interface: power input/output
Signal interface: 3-core XLR signal input/output
Net weight: 19 kg
Size: 420 * 320 * 470MM (L * W * H)
