MG-E035
3W/2W Full Color Animation Laser


3W configuration: R635nm/700mW; G525nm/900mW; B450nm/1.4W
2W configuration: R635nm/500mW; G525nm/500mW; B450/1W
Voltage: AC100-240V 50/60Hz
Rated power: <500W
Galvanometer: 20K (2W) high-speed scanning galvanometer, (25K) 3W high-speed scanning galvanometer, optical angle ±30°; input signal ±5V; linear distortion <2%
Laser Modulation: Analog Modulation
Beam diameter and divergence angle: 5mm: <2mrad
Control mode: voice control (4 modes with black field), self-propelled, master-slave, DMX512 (52CH), SD card control, compatible with ILDA standard computer laser software
Control interface: international general DMX512 interface, international ILDA DB25 interface (Pangolin, moncha, etc.)
Demonstration effect: DMX built-in 160 patterns, SD card unlimited storage, you can select scenes or SD card laser show through DMX.
DMX special effects: double pattern mode, which can respectively break the pen, strobe, rotate, move, roll, divide the picture, gradually draw, change color, change size and other functions
Packing size: 340×310×200mm
N.W: 9.5kg
G.W: 13kg
